Pumps

Centrifugal Monobloc

Salient Features:

1. Monoblocs are manufactured as per IS 9079.
2. Larger bearings ensures long life of the pumpset.
3. Unicasing with central delivery maximizes hydraulic efficiency.
4. High operating efficiency resulting in low power consumption.
5. Good suction lift characteristics.
6. Dynamically balanced rotating parts like rotator & impeller.
7. Designed for wide voltage fluctuation balanced and rigid construction.

DESCRIPTION	MHB
HP Range	3-10 hp
Discharge	1842 – 168 Ipm
Head Range	6 – 54 Mts
Insulation	Class ‘A’
Speed	2880 rpm

Applications:

• Agricultural & Farms.
• Industrial applications.
• Water supply schemes.
• Drip & Sprinkler irrigation.

Enquiry Now

Horizontal Openwell Submersible Pumpset

Salient Features:

1. Openwells are manufactured as per Indian Standard IS 14220.
2. High-grade cast iron for a better life.
3. Designed for wide voltage fluctuation.
4. The openwell submersible can be placed at the bottom of the well.
5. This arrangement does not require a suction pipe.
6. Water can also be drawn from a borewell which is bored at the bottom of the openwell by inserting a suction pipe into the borewell & providing a cooling tank arrangement to keep the monobloc submerged in water.
7. Water lubricated bearings.
8. Highly durable water cooled rewindable motor.
9. Copper rotors for smooth starting.
10. Dynamically balanced rotating parts like rotor & impeller.
11. Can be easily dismantled and repaired.

DESCRIPTION	MHB
HP Range	3-20 hp
Discharge	4000 – 120 Ipm
Head Range	2 – 56 Mts
Insulation	Class ‘B’
Speed	1400 & 2880 rpm

Applications:

• Agriculture & Farms.
• Domestic & Multi-storage buildings.
• Sprinklers & Water fountains.
• Drip irrigation.

Enquiry Now

Single Phase Vertical Openwell Submersible Pumpsets

Salient Features:

1. Openwells are manufactured as per Indian Standard IS 4220.
2. Dynamically balanced rotors and impellers ensure vibration free performance and enhanced life.
3. The openwell submersible monobloc can be placed at the bottom of the well, this arrangement does not require a suction pipe.
4. Water can also be drawn from borewell which is bored at the bottom of the openwell using a suction pipe.
5. Noiseless operation.
6. Can be easily dismantled and repaired.

DESCRIPTION	MHB
HP Range	0.5 – 2.0 hp
Discharge	600 – 30 Ipm
Head Range	7 – 43 Mts
Insulation	Cat ‘B’
Speed	2880 rpm

Applications:

• Domestic supply.
• Car washing.
• Lawns & Gardens.
• Fountains.

Enquiry Now

Single Phase Horizontal Openwell Submersible Pumpsets

Salient Features:

1. Openwells are manufactured as per Indian Standard IS 4220.
2. Dynamically balanced rotors and impellers ensure vibration free performance and enhanced life.
3. The openwell submersible monobloc can be placed at the bottom of the well, this arrangement does not require a suction pipe.
4. Water can also be drawn from borewell which is bored at the bottom of the openwell using a suction pipe.
5. Noiseless operation.
6. Can be easily dismantled and repaired.

DESCRIPTION	MHB
HP Range	0.5 – 1.5 hp
Discharge	100 – 20 Ipm
Head Range	6 – 85 Mts
Insulation	Cat ‘B’
Speed	2880 rpm

Applications:

• Domestic supply.
• Car washing.
• Lawns & Gardens.
• Fountains.

Enquiry Now

80mm Borewell (3”) Water
Cooled Submersible Pumpsets

Salient Features:

1. Motor designed for wide voltage fluctuation.
2. Stainless steel pump shell for corrosion resistance & LTB bushes for higher resistance & longer life.
3. Smooth & Noiseless operation.
4. Light weight & easy to install.
5. Can be easily dismantled & repaired.
6. Dynamically balanced rotating part like rotor and impeller ensures long life.
7. Highly durable water cooled rewindable motor.
8. Low frictions carbon thrust bearings.
9. Stainless steel strainer prevents particles over a certain size from entering the pump.
   Pumps are available with non-return value to reduce the back pressure of water when it is switched off.
10. Non-magnetic, corrosion-resistant, high-grade stainless steel stator body.

DESCRIPTION	MHB
HP Range	0.5 – 1.5 hp
Discharge	90 – 10 Ipm
Head Range	8 – 109 Mts
Insulation	Cat ‘B’
Speed	2880 rpm

Applications:

• Domestic supply.
• Agriculture.
• Small drip irrigation.
• Gardens.

Enquiry Now

100mm Borewell
Water Cooled Submersible Pumpsets

Salient Features:

1. Motor designed for wide voltage fluctuation.
2. Stainless steel pump shell for corrosion resistance & LTB bushes for high wear resistance and & longer life.
3. Smooth and noiseless operation.
4. Light weight & easy to install.
5. Can be easily dismantled & repaired.
6. Dynamically balanced rotating part like rotor and impeller ensures long life.
7. Highly durable water cooled rewindable motor.
8. Low frictions Carbon Thrust Bearings.
9. Stainless steel strainer prevents particles over a certain size from entering the pump.
10. Pumps are available with non-return valve to reduce the back pressure of water when its switched off.
11. Non-magnetic, corrosion-resistant high-grade stainless steel stator body.

DESCRIPTION	MHB
HP Range	1.0 – 1.5 hp
Discharge	100 – 10 Ipm
Head Range	6 – 135 Mts
Insulation	Cat ‘B’
Speed	2880 rpm

Applications:

• Domestic supply.
• Agriculture.
• Small drip irrigation.
• Gardens & Nurseries

Enquiry Now

4” Borewell Submersible Pumpsets

Salient Features:

1. Borewell submersible pump sets as per IS 8034, Motor as per IS 9283.
2. Motor designed for wide voltage fluctuation.
3. Water lubricated bearing.
4. Smooth & Noiseless operation.
5. Light weight & easy to install.
6. Can be easily dismantled & repaired.
7. Dynamically balanced rotating part like rotor and impeller ensures long life.
8. Highly durable water cooled rewindable motor.
9. Low frictions Carbon Thrust Bearing.
10. Stainless steel strainer prevents particles over a certain size from entering the pump.
11. Pumps are available with non-return value to reduce the back pressure of water when it is switched off.
12. Non-magnetic, corrosion-resistant, high-grade stainless steel stator body.

DESCRIPTION	MHB
HP Range	3.0 – 7.5 hp
Discharge	330 – 10 Ipm
Head Range	7 – 508 Mts
Insulation	Cat ‘B’
Speed	2880 rpm

Applications:

• Domestic supply.
• Gardens

Enquiry Now

150mm Borewell Radial Flow Submersible Pumpsets

Salient Features:

1. Motor outer diameter are according to NEMA standard.
2. Water lubricated bearing.
3. Copper rotors for smooth starting.
4. Smooth & Noiseless operation.
5. Non-magnetic, corrosion-resistant, high-garde stainless steel stator body.
6. Can be easily dismantled & repaired.
7. Dynamically balanced rotating part like rotor and impeller.
8. High quality water resistant polymer insulated wires for longer life even under adverse voltage conditions.
9. Low frictions Carbon Thrust Bearing.
10. Individually and accurately balanced impeller gives better performance for lower power consumption

DESCRIPTION	MHB
HP Range	1.5 – 25 hp
Discharge	420 – 30 Ipm
Head Range	13 – 397 Mts
Insulation	Cat ‘B’
Speed	2880 rpm

Applications:

• Agricultural & Farms.
• Sprinkler & Small drip irrigation.
• Nurseries & Gardens.
• Public water supply.

Enquiry Now
